Product Description
Altek Multi-Type Portable, Handheld Thermocouple Calibrator- Model 322-1
Model#: 322-1
The Altek 322-1 is a portable, handheld thermocouple calibrator designed to source (simulate) and read four primary thermocouple types: J, K, T, and E, as well as millivolts.
Key Features and Specifications:
- Thermocouple Support: Dedicated settings for Types J, K, T, and E, plus a millivolt range (-99.999 to 99.999 mV).
- "Quik-Chek" Function: Allows users to store and instantly recall three output temperatures for each thermocouple type (15 total memories) for rapid testing of trip points and hysteresis.
- High Accuracy: Delivers accuracy of 0.008%of reading + 0.006mV, which translates to roughly 0.2°C for supported types.
- Resolution: Field-customizable to display in 0.1° or 1° increments in either °F or °C.
- Protection: Built-in circuitry protects the unit against accidental connections to 120V AC/DC
