Product Description
Omega Handheld Multifunction Calibrator CL123
Part#: CL123
The Omega CL123 is a handheld multifunction calibrator designed to provide precision output signals for simulating various process parameters.
Features:
- 4-20 mA (1K. load, 24 V loop supply)
- 0-100.00 mV, 0-1.0000 V, 0-12.000 V
- K,J,E,T Thermocouples (°C & °F)
- Frequency 1-62500 Hz
- 0-20 mA, 0-24 mA Selectable
- 0-100% range setting in mA, mV, V, mode
- Beeper Warning when Output is Open (mA)
Basic Accuracy: 0.025%
- 0-24 mA ±0.025% ±0.003 mA
- 0-100 mV ±0.05% ±0.03 mV
- 0-1 V ±0.05% ±0.0003 V
- 0-10 V ±0.05% ±0.003 V
Thermocouples:
- K: -200 to 1370, ±0.9°C
- J: -100 to 760, ±0.8°C
- E: -100 to 700, ±0.7°C
- T: -200 to 400, ±0.8°C
- Frequency: 1 to 125 Hz, ±0.04 Hz, 126 to 62,500 Hz, ±0.01% ±0.04 Hz (604 Available Frequencies)
- Thermocouple Connection:SMP (miniature) type on front
- Process Connection:45 cm (18") red and black leads attached to side of unit
