Product Description
SSI Super Systems Multi-Gas IR Analyzer, MGA 6010
Model: MGA 6010
Multi-Gas IR Analyzer (CO, CO2, and CH4 Gas Analyzer with Optional H2 Measurement and % Carbon, % Dissociated Ammonia, % NH3, KN, and KC Calculation Capabilities)
The Model MGA 6010 is a Multi-Gas IR analyzer. It measures Carbon Monoxide (CO), Carbon Dioxide (CO2) and Natural Gas (CH4) typically found in an endothermic atmosphere. The measurement of these gases, combined with furnace temperature information, allows the MGA 6010 to calculate the percent Carbon (%C) of the measured gas. A Hydrogen (H2) sensor can also be incorporated as an option to provide a more complete picture of the measured gas. For nitriding and ferritic nitrocarburizing (FNC) applications, the MGA 6010 can calculate carburizing potential (KC) and nitriding potential (KN).
Specifications
The unit is designed and manufactured for the atmosphere heat treating industry; however, its uses go beyond the scope of these applications.
- CO range: 0.00 to 30.00 %
- CO2 range: 0.000 to 2.000 %
- CH4 range: 0.00 to 15.00 %
- H2 range: 0.00 to 100%
- Sampling method: Extraction by internal pump (when necessary)
- Measurement Method (CO, CO2, CH4): Non-Dispersive Infrared (NDIR)
- Measurement Method (H2): Thermal Conductivity
- Accuracy and repeatability: 1% of full scale
- Recommended Calibration Interval: Annual
- AC Power Requirements: 110VAC
- Communications: Ethernet, USB(A), USB(B), RS485 Modbus
- Data Storage: Continuous automatic data logging
