Product Description
White-Rogers 11B18-101 Well Immersion Control w/ 100-240°F Range (Open On Rise)
PN: 11B18-101
Features
- Well Immersion Single Control
- SPST
- Open On Rise
- 100-240 Degrees F Range
- 5-45 Degrees F Adjustable Differential
- Vertical Or Horizontal Mounting
- 1/2" Standard Shank Well Included
Specifications
- Application: High Limit
- Switch Action: SPST Contacts Break on Temp Rise
- Differential: Adjustable 5° to 45°F
- Max Temp Differential: 45°F
- Electrical Rating: 7A @ 240V, 14A @ 120V
- Height (Inches): 5.375"
- Width: 2-5/16"
- Depth (Inches): 2-9/16"
- Color: Gray
- Min Temp Differential: 5°F
- Well Included: Yes
- Well Spud Size: 1/2" NPT
- Mount: Vertical, Horizontal
- Temperature Range (F): 100°F to 240°F
