Product Description
Panduit LCA500-58-6 Pan-Lug Copper 1 Hole Straight Tongue Compression Lug
Part#: LCA500-58-6
The Panduit LCA500-58-6 is a premium, one-hole copper compression lug from the Pan-Lug series. It is specifically engineered to create reliable, high-conductivity electrical terminations for heavy-duty power and grounding systems.
- Product Type: Compression Lug
- Base Material: Copper
- Number of Stud: Holes 1
- Barrel Type: Standard
- Barrel Entry: Beveled
- Tongue Type: Standard
- Tongue Angle: Straight
- Inspection Window: Yes
- Finish/Coating: Tin-Plated
- Stud Hole Size (In.): 5/8
- Stud Hole Size (mm): 15.9
- Stud Hole Spacing (mm): 0
- Copper Conductor Size: 500 kcmil
- Barrel Length (In.): 1.75
- Barrel Length (mm): 44.5
- Tongue Width (In.): 1.54
- Tongue Width (mm): 39.1
- Tongue Thickness (In.): 0.22
- Tongue Thickness (mm): 5.6
- Overall Length (In.): 3.76
- Overall Length (mm): 95.5
- Standards Met: UL Listed to 486A-486B File #E52164, NEBS Level 3, ABS
- CSA Temperature Rating (°C): 90
- UL Temperature Rating (°C): 90
- Maximum Voltage (kV): 35
- Color Code: Brown
- Panduit Die Index Number: P87
- Burndy Die Index Number: 20
- T & B Die Index Number: 87
- Wire Strip Length (In.): 1-13/16
- Wire Strip Length (mm): 46
