Product Description
IKO CF-10-1-YBUUR Cam Follower Bearing- Box of 2
Part#: CF-10-1-YBUUR
- Roller Outer Diameter (D): 26 mm
- Outer Ring Roller Width (C): 12 mm
- Stud Diameter (d₁): 10 mm
- Stud Length (B₂): 23 mm
- Thread Size (G): M10 x 1.25
- Thread Length (G₁): 12 mm
- Total Component Length (B₁): 36.2 mm
- Outer Ring Width inc. Side Plate (B): 13.2 mm
- Hex Socket Drive Size (H): 4 mm
- Minimum Mounting Shoulder Diameter (????): 16 mm
- Basic Dynamic Load Rating (C): 5,430 N
- Basic Static Load Rating (C₀): 6,890 N
- Maximum Allowable Static Load: 6,890 N
- Maximum Tightening Torque: 13.8 N·m (approx. 10.18 lbf·ft)
- Operating Temperature Limits: -20°C to +80°C (-4°F to +176°F)
