Product Description
Honeywell Q179A1118 LPG Pilot Burner w/Flame Rod and Electrode
Q179A is a gas pilot assembly (with a flame electrode rod) and ignition electrode, making it suitable for applications requiring an interrupted or intermittent electrically ignited gas pilot burner.
- Q179B has only the flame electrode and is suitable for use in continuous pilot applications.
- Primary aerated type burner is equipped with stainless steel fins that provide the proper flame rod area to ground area ratio for maximum flame signal and flame stabilization.
- Stainless steel electrode(s) are mounted in ceramic insulators, which permit electrode adjustment.
- Rajah connectors facilitate disconnecting (A1126 has terminal screws).
- Bracket permits side or end mounting.
- Mounting Bracket side/end
- Port and Burner Tip Style 45 degree left hand
- Overview Q179A,B Gas Pilot Burner Assemblies use the flame rectification principle to prove the flame. Q179A,B are used in conjunction with a suitable electronic flame safeguard control on industrial or commercial gas and gas pilot ignited oil burners.
- Gas Consumption 2.0 cfh (0.06 m3/hr)
- Aeration Primary
- Includes Flame electrode and ignition electrode
- Used With Q624 or other suitable ignition transformer.
- Application For Intermittent or Interrupted Ignition
- Type of Gas Natural
- Orifice 0.025 in. dia. (0.635 mm dia.)
- Gas Fitting 1/4 in. compression coupling
- Approvals, Underwriters Laboratories Inc Listed: File No. MP268, Guide No. MCCZ
- Approvals, Canadian Standards Association Certified: File No. LR1620, Guide No. 140-A-2
- Approvals, Factory Mutual Approved: Report No. 22961
- Wiring Terminal Type Rajah
