Product Description
Fafnir LAO1 15/16 Pillow Block Ball Bearing Unit
Two-Bolt Base, 1.9375 in Bore, Cast Iron Material, Heavy Duty, Non-Expansion Bearing (Fixed)
| Mounting | Two-Bolt Base |
|---|---|
| Housing Material | Cast Iron |
| Bore Diameter | 1.9375 in |
| Bolt Center-to-Center Length | 8.2500 in |
| Base to Bore Centerline | 2.8125 in |
| Duty Type | Heavy Duty |
| Locking Device | Eccentric Collar |
| Seal Type | Labyrinth |
| Expansion Type | Non-Expansion Bearing (Fixed) |
| Overall Height | 5.5625 in |
| Overall Length | 10.4375 in |
| Base Width | 2-7/8 in |
| Overall Width | 2-5/8 in |
| Finish/Coating | Uncoated |
| Bore Type | Round |
| Operating Temperature Range | Maximum of +250 °F |
| Radial Dynamic Load Capacity | 15300 lb |
| Radial Static Load Capacity | 8500 lb |
| Maximum RPM | 4380 RPM |
| Lubrication Type | Cannot Be Relubricated |
| Series | LAO |
| Replacement Bearing | GN115KLLB |
| Weight | 13.80 lbs |
