Product Description
Browning HQ1 Hub for Split Taper Bushing
PN: HQ1
- Bushing Size: Q1
- Material: Sintered Steel, Malleable Iron or Ductile Iron
- Outside Diameter: 4-1/2 in
- Pilot Diameter: 4-3/8 in
- Hub Bore Diameter: 2-7/8 in
- Overall Length: 1-3/4 in
- Hub Bore Type: Finished with Keyway
- Keyway Size: 1/2 (Width) in
- Bolt Circle Diameter: 3-3/8 in
- Number Of Bolt Holes: 3
- Screw Thread Size: 3/8-16 in
- Mounting Type: Conventional
