Product Description
Advantech EKI-2525 Unmanaged Ethernet Switch
Part#: EKI-2525
- Provides 5/8 Fast Ethernet ports with Auto MDI/MDI-X
- Supports 10/100 Mbps Auto-Negotiation
- Provides compact size with DIN-rail/Wall mount, and IP30 metal mechanism
- Supports redundant 12 ~ 48 VDC power input and P-Fail relay
General
- Ethernet Port Count: 5
- Mounting: DIN, Panel
- Power: 12-48VDC
- Technology: Ethernet
- Temperature: -10 to 60C
- Unmanaged: Yes
Certification
- EMI: CE, FCC Class A
- EMS: EN 61000-4-2, EN 61000-4-3, EN 61000-4-4, EN 61000-4-5, EN 61000-4-6, EN 61000-4-8
- Safety: UL 60950-1
Environment
- Temperature (Min. Operating): -10°C (14°F)
- Temperature (Max. Operating): 60°C (140°F)
- Operating Temperature: -10 ~ 60°C (14 ~ 140°F)
- Storage Temperature: -40 ~ 85°C (-40 ~ 185°F)
Ethernet Communication
- RJ-45 Port Number: 5
- RJ-45 Port Connector Type: RJ-45
- RJ-45 Transmission Distance: 100 m
- RJ-45 Transmission Speed: 10/100 Mbps
Mechanism
- Mounting (DIN-rail): Yes
- Mounting (Wall): Yes
- Dimensions (W x H x D): 30 x 120 x 95 mm (1.18 x 4.72 x 3.74 in.)
- IP Rating: IP30
PoE Information
- Support PoE: No
Power
- Power Connector Type: 6-pin removable screw terminal
- Power Consumption: 2.88W
- Power Input (DC): 12 ~ 48 VDC
