Product Description
Watlow D24SX5S Duct Heater, 480V, 36KW, 3PH
PN: D24SX5S
Constructed of sturdy 0.430 in. (11 mm) diameter WATROD™ heating elements mounted to a 1/4 in. (6 mm) thick steel flange, duct heaters are easily adapted to many non-pressurized air-heating systems. They are easily installed in applications requiring a wide range of temperature versus air flow combinations.
Size
- OAH: 28"
- Flange: 12" X 10-1/2"
- Element Height: 20"
Specifications
- Voltage: 480
- Kilowatts: 36
- Watt Density: (calculated) 28.6
- B Dimension (Immersed element length): 20
- Number of Elements: 24 elements
- Electrical Phase: 3 Phase Delta wiring
- Wired PAR or SER: Parallel
- Insulation Thickness (in.): 3.5 in.
- Insulation Material: Fiberglass 450F max
- Housing: General Purpose (incl. CSA)
- Hilimit Sensor: No Sensor
