Product Description
Super Systems 31334 Temperature and Hi-Limit Controller
P/N: 3204I/FM/VH/RXXX/R/4XL/G/ENG/ENG/XX/XXXXX/XXXXX/XXXXX/EU0800
Affordable 1/4 DIN temperature and high limit controllers for heating and cooling applications. Universal inputs with relay and analog outputs allowing for several different uses in thermal processing applications.
Tech Specs
Line Rating: 100-230Vac +/-15% 48-62Hz 8W
Relay Rating: 2A 240Vac Resistive
Logic Input: Contact Closure 12Vdc@12mA
Transmitter: 24Vdc@30mA max
DC Output: 0-10V, 0-20mA
1/4 DIN High Limit controller (PN 31334)
Universal input
One FM Relay
Two alarm relay outputs
RS 485 Communications
Type: 3 - Form A / 1 - Form C
Rating: Min 100mA@ 12vdc, max 2A@264Vac resistive
Functions: Control outputs, alarms, events
