Product Description
Seal Master MP-56 Pillow Block Bearing 3-1/2"
PN: MP-56
- Bearing Insert Type: Ball
- Bore Dia.: 3 1/2 in
- Shaft Locking Type: Set Screw
- Bearing Housing Material Type: Cast Iron
- Bearing Insert Material: 52100 Chrome Steel
- Bolt Hole Center-to-Center: 11 1/8 in
- Mounting Surface to Shaft Center: 4 in
- Series: MP
- Number of Bolts: 2
- Dimension G: 1 5/16 in
- Static Load Capacity: 16,301 lbs.
- Overall Width: 4 3/8 in
- Dynamic Load Capacity: 21,566 lbs.
- Overall Length: 15 in
- Dimension C: 9-5/8 in to 12-5/8 in
- Dimension A: 4 in
- Bolt Size: 7/8 in
- Dimension H: 8 1/4 in
- Housing Material: Cast iron
- Locking Type: Set Screw
- Dimension L: 4 25/64 in
- Overall, Height: 8 1/4 in
- Dimension E: 2 5/16 in
- Bearing Lubrication: Seal master Gold Plex-HP or NLGI #2 Equivalent
- Dimension D: 4 3/8 in
- Item: Pillow Block Bearing
- Temp. Range: -20 Degrees to 220 Degrees F
- Dimension B: 15 in
- Dimension J: 3 25/32 in
- Dimension F: 15/16 in
- Finish: black oxide
