Product Description
Releco MR-C Series V Plug In Power Relay, C3-A 30 FX With Base, E92191
Relay PN: C3-A 30FX
Base PN: E92191
The Releco MR-C Series V Plug In Power Relay, C3-A 30 FX With Base, E92191 is a 60Hz, 5 HP rated general purpose industrial electric motor with an indicator holder.
- Maximum contact load: 10 A/250 VAC 0,5 A/110 V DC1 / 10 A/30 VDC 0,2 A/220 V DC1
- Recommended minimum contact load: 1 mA/10 V (with 10 µm Au) / 10 mA/10 V (standard contact)
- Material Standard Code 0: AgNi
- Optional Code 8: AgNi + 10 µ Au
- Rated current: 10 A
- Switch-on current max. (20 ms): 30 A
- Switching voltage max.: 250 V
- AC load: 2,5 kVA
