Product Description
Pepperl + Fuchs NBB10-30GM60-WS-T Inductive Sensor
PN: NBB10-30GM60-WS-T
The Pepperl+Fuchs NBB10-30GM60-WS-T is an inductive sensor that is new and has a 20-250VAC 45-65Hz condition. It has a normally open (NO) switching function, a two-wire output type, and a rated operating distance of 10 mm. It also has a flush installation.
- Switching function Normally open: (NO)
- Output type: Two-wire
- Rated operating distance: 10 mm
- Installation: flush
- Output polarity: AC
- Assured operating distance: 0 ... 8.1 mm
- Actual operating distance: 9 ... 11 mm typ.
- Reduction factor rAl: 0.29
- Reduction factor rCu: 0.26
- Reduction factor r304: 0.71
- Output type: 2-wire
- Operating voltage: 20 ... 253 V
- Switching frequency: 0 ... 20 Hz
- Hysteresis typ: 5 %
- Voltage drop: ≤ 8 V
- Momentary current: (20 ms, 0.1 Hz) 0 ... 1600 mA
- Operating current: 5 ... 200 mA
- Off-state current: 0 ... 1.7 mA typ.
- Time delay before availability: ≤ 30 ms
- Operating voltage indicator: LED, green
- Switching state indicator: LED, yellow
- Standards: IEC / EN 60947-5-2:2004
- CCC approval: Certified by China Compulsory Certification (CCC)
- Ambient temperature: -25 ... 70 °C (-13 ... 158 °F)
- Cable version: PA
- Core cross-section: 0.34 mm2
- Housing material: brass, nickel-plated
- Sensing face: PBT
- Degree of protection: IP67
