Product Description
NAIS FPO-C16TT03 Control Unit
PN: FPO-C16TT03
Panasonic Electric Works established a new world standard "SLIM" PLC. Starting from 10 I/O to 32 I/O, the CPU is only 25(w) x 90(h) x
70(d)mm. This is about 1/4 the size of the traditional bulky PLC style called "Brick". The FP0 saves precious panel space and money.
Relay output types have removable screw terminal blocks. The power supply connector is also quick to disconnect. Easy installation...
especially when duplicating many systems.
- Pulse Outputs: 2
- DC Inputs: 8
- Npn Outputs: 8
- Program Size(K): 2.7
- Rated operating voltage: 24 VDC
- Operating voltage range: 21.6 to 26.4 VDC
- Ambient temperature: 0°C to +55°C
- Storage temperature: -20°C to +70°C
- Ambient humidity: 30 to 85% RH (Non-condensing)
- Storage humidity: 30 to 85% RH (Non-condensing)
- Breakdown voltage: Between input/output terminals and power/ground terminals: 500VAC for 1 minute (for the relay output type, 1500VAC for 1 minute)
- Between input terminals and output terminals: 500VAC for 1 minute (for the relay output type, 1500VAC for 1 minute)
- Insulation resistance: Between input/output terminals and power/ground terminals: Over 100 MΩ (using a 500VDC megger) Between input terminals and output terminals: Over 100MΩ (using a 500VDC megger)
- Vibration resistance: 10 to 55Hz, 1 sweep/min., double amplitude of 0.75mm, 10min. on 3 axes
- Shock resistance: 98m/s 2 or more, 4 times on 3 axes
- Noise immunity: 1,000 V(p-p) with pulse widths 50ns and 1ms (using a noise simulator)
