Product Description
McMaster-Carr 98404A872Stainless Steel Quick Release Pins 1" x 4"
The smooth ring handle on these pins won't catch on parts. A spring-loaded, nonlocking retaining ball pops out to hold pins in place. The hole should be as close to the diameter as possible, but not larger than the diameter at extended ball height. The ends are chamfered for easy insertion. Breaking strength is measured as single shear, which is the force required to break the pin into two pieces. Also known as faspins.
18-8 stainless steel pins offer a balance of strength and corrosion resistance. They may be mildly magnetic.
Tech Specs:
Pin Type Quick Release
End Type Spring-Loaded Ball
Head Type Ring
Shaft Type Plain
End Shape Chamfered
System of Measurement Inch
Material 18-8 Stainless Steel
Usable Length 4"
Diameter 1"
Diameter Tolerance -0.003" to 0"
Diameter at Extended Ball Height 1.14"
Min. Hardness Rockwell B85
Breaking Strength 79,000 lbs.
Number of Retaining Balls 1
Ball Material 316 Stainless Steel
Spring Material 316 Stainless Steel
Handle Material 316 Stainless Steel
Lock Type Nonlocking
Passivation Not Passivated
