Product Description
Ideal 46-382 Medium Wall Heat Shrink End Cap, Pack of 4
PN: 46-382
The Ideal 46-382 Medium Wall Heat Shrink End Cap is a 4 in long, medium-wall heat shrink end cap that is black and made of polyolefin. It has a thickness of 0.091 in and a 4-3/0 AWG. The end cap protects against oxidation, ozone, UV radiation, and more.
- Creates a watertight seal to protect ends of power and control cords
- Protects against oxidation, ozone, UV radiation, etc.
- Coated with hot melt adhesive to ensure environment seal
- Fits easily over end of cable
- Protect power cables up to 1000V and telecommunication cable
- Recommended for both open air and underground power distribution cables with PVC, lead or XLPE sheaths
- Thermally stabilized cross-linked polylefin, coated with specially designed hot melt adhesive
- UV resistant
- Qty: 4
- Diameter Before Shrinking: 0.98 in
- I.D. After Shrinking: 0.31 in
- Temp. Range: -55° to 110°F
- Shrink Ratio: 3:1
- Length: 2.75 in
- Tubing Wall Type: Medium Wall
- Use With Wire Size4 AWG to 3/0 AWG
- Wall Thickness After Shrinking: 0.09 in
- Material: Cross-Linked Polyolefin with Adhesive
- Shrink Tubing Properties: UV Light Resistant
- Flame Retardant: No
- Color: Black
- Adhesive Lined: Yes
- Application: General
- Dielectric Strength: 1,000 V
- Min. Shrink Temp: 248 °F
- Features: Recommended for Open Air and Underground Power Distribution Cables With PVC, Lead, or XLPE Sheaths Standards: RoHS
- Max. Temp. Rating: 110 °F
- Min. Temp. Rating: -55 °F
