Product Description
Festo SIM-M12-4GD-5-PU Connecting Cable
Part#: SIM-M12-4GD-5-PU
Festo SIM-M12-4GD-5-PU is a connecting cable for sensors and proximity switches that conforms to EN 61076-2-101 and EN 61984 standards. It has a 5-pin/4-wire electrical connection with a straight socket/open end and M12x1 / -. It also has a plug coding of A and an operating voltage range of 0–250 V for both DC and AC
- Cable length: 5 m
- Conforms to standard: EN 61076-2-101, EN 61984
- Electrical connection: 5-pin/4-wire, Straight socket/open end M12x1 / -
- Plug coding: A
- DC operating voltage range: 0 V ... 250 V
- Operating voltage range AC: 0 V ... 250 V
- Current rating at 40° C: 4 A
- Surge resistance: 2.5 kV
- Cable characteristic: Standard
- Connector cable test conditions
- Test conditions on request: bending radius 75 mm
- Cable diameter: 4.5 mm
- Cable design: 4 x 0.25 mm²
- Nominal conductor cross section: 0.25 mm²
- Wire insulation color code: Blue, Brown, Black, White
- Degree of protection: IP65, IP68
- Ambient temperature: -25 °C ... 80 °C
- Ambient temperature with flexible cable installation: -5 °C ... 80 °C
- Note on materials: RoHS-compliant, Halogen-free, Free of phosphoric acid ester
- Contamination level: 3
- Corrosion resistance class (CRC): 2 - Moderate corrosion stress
- Material of cable sheath: TPE-U(PU)
- Color cable sheath: Gray
- Housing material: TPE-U(PU)
- Housing color: Black
- Material of union nut: Brass, nickel-plated
- Seals material: NBR
- Material of pin contacts: Brass, gold-plated
- Insulating sheath material: PP
