Product Description
Festo GRA-1/4-B Flow Control Valve
Flow Control Valve, one way, 420L/min, G 1/4
- Type code: GRA
- Valve function: Flow control non-return function
- Pneumatic connection 1: G1/4
- Pneumatic connection 2: G¼
- Adjusting element: Knurled screw
- Type of mounting- Optionally: Front panel mounting, With through-hole
- Standard nominal flow rate in flow control direction: 420 l/min
- Standard nominal flow rate in non-return direction: 780 l/min
- Operating pressure: 0.1 bar ... 10 bar
- Ambient temperature: -20 °C ... 75 °C
- Housing material: Die-cast zinc
- Temperature of medium-20 °C ... 75 °C
- Product weight: 180 g
- Material of adjusting screw: Brass
