Product Description
Eaton / Cutler Hammer WMZS1D03 Supplementary Protector; 3 Amp, 277 Volt AC, 48 Volt DC, 1-Pole, DIN Rail Mount
Detailed Description: Eaton 1-Pole Supplementary protector features a color-coded red/green indicator that provides easy visual indication of device status/isolation. Circuit breaker can be mounted on a standard 35 mm DIN rail. It has box terminals that accept multiple conductors and bus connectors/feeder terminals that facilitate quick mounting/wiring. Power to the circuit breakers can be fed from the line/load side. It is designed to provide fast short-circuit protection that reduces damage to the circuit. It has a current rating of 3 Amp and a voltage rating of 277 VAC, 48 VDC. It has a current interruption rating of 5 kilo-Amps. Circuit breaker measures 0.700 Inch x 2.250 Inch x 3.150 Inch.
Circuit breaker has type C protective curve that makes it suitable for applications where medium level of inrush current is expected. It is designed for inductive loads. Circuit breaker is suitable for small transformers/lighting/pilot devices/control circuits/coils. It is ideal for international and domestic use. It has medium magnetic trip point and an instantaneous trip response time of 10 to 20 times the current rating. Circuit breaker meets UL/CSA/IEC/CE/RoHS standards.
Product Specification
| Amperage Rating | 3 |
| Application | Circuit Protection |
| Brand | Eaton |
| Catalog Description | UL 1077 WMZS DIN Rail Supplementary Protector, 10 kAIC at 277/480V, Single-pole, D Curve, 3A, Standard box terminals |
| Circuit Protection | D Curve |
| GTIN |
00786685258799 |
| Height | 3.15 |
| Height Unit | IN |
| Interrupt Rating | 10 kAIC at 277/480 Vac |
| Item Status | A |
| Length | 0.69 |
| Length UOM | IN |
| Mfr. # | WMZS1D03 |
| Number Of Poles | 1 |
| Ships Freight | No |
| Ships Ground. Eligible for expedited shipping | Yes |
| Standard | IEC 60947-2;CSA Std. C22.2 No. 235;UL 1077;CE Marked;RoHS Compliant |
| Terminals | Standard box terminals |
| Type | DIN rail mountable circuit breaker |
| UNSPSC | 39121603 |
| Voltage Rating | 277/480 |
| Width | 3.01 |
| Width UOM | IN |
