Product Description
Dwyer VFA-2-BV Visi-Float Acrylic Flow Meter, 0-2.0 SCFH Air
PN: VFA-2-BV
The Series VF Visi-Float® Flowmeters are a line of direct reading, precision machined, clear acrylic body flowmeters suitable for both gas and liquid applications. The fabrication of the Visi-Float® flowmeters is backed by over 60 years of experience in acrylic instrument machining. This Series consists of 2" (51 mm) and 4" (102 mm) scales with optional precision metering valves.
- Service: Air
- Body: Acrylic plastic; O-ring: Buna-N
- Metal parts: Nickel plated brass standard
- Temperature & Pressure Limits: 100 psig (6.9 bar) @ 120°F (48°C)
- Accuracy: VFA = 5% of FS
- Process Connection: 1/8" female NPT
