Product Description
Dodge 2517 1 3/4'' Taper-Lock Bushing
PN: 2517
| Bore Diameter | 1.7500 in |
|---|---|
| Outside Diameter | 3-3/8 in |
| Length Through Bore | 1.75 |
| Bushing Size | 2517 |
| Bore Type | Finished w/ Keyway |
| Keyway Size | 3/8 x 3/16 in |
| Material | STEEL |
| Screw Torque | 430 in-lbs |
| Maximum Hub Outside Diameter | 5-1/2 in, 4-7/8 in, 4-3/8 in |
| Bolt Circle Diameter | 3-1/4 in |
| Number of Bolt Holes | 2 |
| Screw Thread Size | 1/2-13 in |
| Screw Length | 1 in |
