Product Description
Dayton 29HZ07 Coupling Insert
Technical Specs
- Item - Jaw Coupling SpidersJaw Coupling Insert
- Size - Jaw CouplingsL099/L100
- Material - SpidersBuna N
- Rated Torque415 in.-lb.
- Max. RPM7000
- HP Rating @ 100 RPM0.49/0.65
- Temp. Range104 Degrees to 212 Degrees F
- HP Rating @ 1200 RPM5.99/7.9
- HP Rating @ 1800 RPM8.99/11.85
- HP Rating @ 3600 RPM17.99/23.7
- Coupling Weight (Lb.)0.075
- Max. Parallel Misalignment (In.)0.015
- Max. Angular Misalignment1 Degrees
- Shaft Dia. Range (In.)7/16 - 1-3/8
- ColorBlack
- Length (In.)0.63
- Width (In.)2.52
- Height (In.)2.52
- Accommodates1 Degree Angular and 0.015" of Parallel Misalignment
- ApplicationClose Coupling L-Type
