Product Description
Banner Barrel Table Sensor SM30SRLQD
Part#: SM30SRLQD
The Banner SM30SRLQD Barrel Table Sensor is a photoelectric sensor that has a range of 150m and an input of 10-30 V dc. It is a receiver and has a bi-modal output of 1 NPN
SM30 SERIES 150 M RANGE OPPOSED MODE BARREL SENSOR
- IP Rating: IP67
- Sensing Beam: Infrared LED
- Power: DC
- Sensing Mode (General): Opposed
- Sensing Mode (Detailed): Receiver
- Housing Style: Barrel
- Primary Housing Material: Stainless Steel
- Input Output: Discrete
- Max Sensing Distance (mm): 150000
- Outputs: Bipolar (NPN & PNP)
- Power Supply/Supply Voltage: 10-30 V dc
- Connection: Integral QD
- Quick Disconnect Type: 7/8 in. (Mini)
- Min Op. Temp. (°C): -40
- Operation: Light/Dark Operate
- Max Op. Temp. (°C): 70
- Output response time (ms): 10
- Special Feature: Intrinsically Safe: No
- Special Feature: Remote Teach: No
- Special Feature: Water Detection: No
- Delay at Power-up (ms): N/A
- Repeatability (µs): 1000
- Number of Pins: 4
- NEMA Rating: NEMA 6P
- Max Op. Relative Humidity [%]: 90% @ 50°C
- Lens Material: Acrylic
- Adjustments: N/A
- Barrel Diameter (mm)30
- Indicator: LEDs
- Opposed Mode Emitter/Receiver: Receiver
- Feature: Encapsulated: Yes
- Feature: Audible: No
- Feature: Chemical Resistant: Yes
- Feature: Quick Disconnect: Yes
