Product Description
Baldor ECP83771T-4 Motor 10HP, 3475RPM, 3PH, 60HZ, 215T, 0742M, TEFC, F1
Part#: ECP83771T-4
The Baldor ECP83771T-4 is a severe duty motor designed to protect motors from harsh environmental conditions. These motors are available from 1 HP to 700 HP and are often used in applications such as petro-chemical plants, mines, foundries, pulp and paper plants, waste management facilities, rock crushers, and chemical plants.
- HP: 10 TE
- IP: 56
- VOLTS: 460
- AMPS: 11.3
- R.P.M.: 3500
- FRAME: 215T
- HZ: 60
- PH: 3
- SER.F.: 1.15
- CODE: H
- DES.: B
- CLASS: F
- RATING: 40C AMB-CONT
- NEMA NOM. EFF.: 91
- P.F.: 91
- GUAR. MIN. EFF.: 89.5
- CC: 010A
- T. CODE: T3C
- TEMP= 160
- NP4328
- GREASE: POLYREX EM
- MOTOR WEIGHT: 225
- ROTOR BARS: 28
- STATOR BARS: 36
- MAX. R.P.M.: 5400
- MAX. KVAR N/A
- INV.TYPE: PWM
