Product Description
Acopian W90GT10.1 Power Supply
PN: W90GT10.1
Input Voltage: 90-132 VAC, 49-61 Hz, single phase.
For models W12GT95, W15GT78, W24GT50, W28GT42 and W48GT25: the use of a 30A line is recommended and when operating on 50 Hz input, derate output by 5%.
Startup Time: 400 mS maximum (250 mS typical.)
Input Undervoltage: An input of less than 90 VAC (180 VAC with "-230" option) will not damage power supply.
Load Regulation:
3.3v to 48v Models: ±0.05% or 5 mV, whichever is greater.
50v to 125v Models: ±0.1%
Line Regulation:
3.3v to 48v Models: ±0.05% or 5 mV, whichever is greater.
50v to 125v Models: ±0.1%
Remote Voltage Programming: The output voltage of all models may be controlled by means of an external 2,500 ohm potentiometer.
Polarity: Output is floating and may be used in either polarity.
Drift: ±0.1% maximum over 8 hours, after 30 minute warmup.
Temperature Coefficient: ±0.02%/°C (Typical).
Holdup Time: 33mS minimum (At nominal input voltage, with full load).
Transient Response: 300 uS to return to ±1% of output setting. Maximum of ±3% output excursion following a load step change from 50% to 100%.
Remote Sensing: Compensates up to 0.5 volt drop per output line, within the limits of the output voltage adjustment range.
Overload/Short Circuit Protection: Foldback current limiting with automatic recovery.
Overvoltage Protection: Latches power supply OFF, reset by momentarily removing AC input power. Red indicator lights to indicate latchup.
Output Inhibit: Applying between +2 and +30 Vdc to the inhibit terminal will disable the supply (TTL compatible).
Thermal Protection: Thermostat, self-resetting.
Efficiency: See Output Specs. (Typical, at nominal input voltage, with full load.)
Ambient Operating Temperature: 0 to +71°C.
Storage Temperature: -40 to +85°C.
Cooling: Forced-air cooled (ball bearing fan); air enters back of power supply and exits from front.
Switching Frequency: 55 kHz (Typical).
- Input Voltage Range:90 to 132
- Nominal Output Voltage:90*
- Output Current Amps:10.1
- Case Size:WG7
- Input Voltage Range:90 to 132
- Nominal Output Voltage:90*
- Output Current Amps:10.1
- Case Size:WG7
